Menşe yeri:
Çin
Marka adı:
Hengyang
Sertifika:
ISO9001
Model numarası:
HY-126
Bilyalı Değirmen Teknik Detayları:
| modeli | Silindir dönüş hızı (r/dak) | Top ağırlığı yükleme (t) | Giriş boyutu (mm) | Deşarj boyutu (mm) | Kapasite(t/saat) | Motor gücü (kw) | Ağırlık (t) |
| Ø900×1800 | 39 | 1.5 | ≤20 | 0.075-0.89 | 0.6-1.5 | 18.5 | 4.6 |
| Ø900×3000 | 39 | 2.7 | ≤20 | 0.075-0.89 | 1~4 | 22 | 5.6 |
| Ø1200×4500 | 32 | 5 | ≤25 | 0.074-0.4 | 1.6-5.8 | 55 | 13.8 |
| Ø1500×3000 | 27 | 7.5 | ≤25 | 0.074-0.4 | 2~5 | 75 | 15.6 |
| Ø1500×5700 | 28 | 12 | ≤25 | 0.074-0.4 | 3.5-6 | 130 | 24.7 |
| Ø1830×3000 | 25 | 11 | ≤25 | 0.074-0.4 | 4~10 | 130 | 28 |
| Ø1830×6400 | 24 | 21 | ≤25 | 0.074-0.4 | 7~16 | 210 | 34 |
| Ø2100×3600 | 23 | 19 | ≤25 | 0.074-0.4 | 10-36 | 210 | 46 |
| Ø2200×4500 | 21 | 27 | ≤25 | 0.074-0.4 | 12~23 | 280 | 48.5 |
| Ø2200×6500 | 21 | 35 | ≤25 | 0.074-0.4 | 14-26 | 380 | 52.8 |
| Ø2200×7000 | 21 | 35 | ≤25 | 0.074-0.4 | 15-28 | 380 | 54 |
| Ø2200×7500 | 21 | 35 | ≤25 | 0.074-0.4 | 15-30 | 380 | 56 |
| Ø2400×4500 | 21 | 30 | ≤25 | 0.074-0.4 | 18-45 | 320 | 65 |
| Ø2700×3600 | 21 | 39 | ≤25 | 0.074-0.4 | 19-75 | 400 | 83 |
| Ø2700×4500 | 20 | 48 | ≤25 | 0.074-0.4 | 22-85 | 430 | 89 |
| Ø3200×4500 | 18 | 65 | ≤25 | 0.074-0.4 | 29-140 | 800 | 137 |
| Ø3200×5400 | 18 | 81.6 | ≤25 | 0.074-0.4 | 30-180 | 800-1000 | 146 |
| Ø3600×4500 | 17 | 88 | ≤25 | 0.074-0.4 | 35-210 | 1000 | 190 |
| Ø3600×8500 | 17 | 144 | ≤25 | 0.074-0.4 | 45-260 | 1800 | 260 |
